Product Details:
|
| Battery Type: | 18650 Rechargeable Li-ion | Battery Size: | 18.4*65.1mm |
|---|---|---|---|
| Weight: | 48g | Nominal Voltage: | 3.6V |
| OEM/ODM: | Accepatable | Cycle Life: | 500 Times |
| High Light: | 3.6V Rechargeable Lithium Battery 2200mah,3.6V Lithium Ion Battery For Scooter,18650 Rechargeable Lithium Battery 2200mah |
||
1. Light, small, high energy density and long cycle life.
2. High safety, meeting international safety standards such as UL, CE, EN62133, etc.
3. Wide operating temperature range, stable performance under high and low temperature.
4. A variety of cell types for choice, suitable for many different product fields.
5. Independent development and design, can be customized as per customers' producy requirements.
| Application field of lithium battery | |||||
| No. | Traffic Power Source | Electric Energy Storage Power Source | Mobile Communication Power Supply | New energy storage power supply | Aerospace Military Power Supply |
| 1 | Electric bicycle | Large solar/wind energy storage system | Acer station integrated lithium battery power supply | Solar street lamp, lawn lamp, mine lamp, emergency lamp, garden lamp, high pole lamp | Power supply for large ships (airline, war ship, large cruise ship, cargo ship, etc.) |
| 2 | Battery-operated motor cycle; Electric motorcycle; E-scooter |
Grid peak regulation power supply | Lithium battery power supply for outdoor integrated base station | Starting power source (starting power source for automobile, motorcycle, railway diesel locomotive, electric locomotive, bus, etc.) | Power supply for aircraft (power supply for large civil aircraft, commercial aircraft, helicopter, fighter aircraft and other flight instruments) |
| 3 | EV; Electric vehicles; Cell-driven vehicles (Hybrid and pure) |
Special uninterruptible power supply system for power | Marginal network base station lithium battery power supply | Power tools (drill, grinder, electric nuts, etc.) | Space vehicle power supply system (space shuttle, satellite, rocket, missile, etc.) |
| 4 | Electric bus/Medium bus (Hybrid and pure) |
Integrated power system | Non-physical site lithium battery backup power | Battery-operated toy | Military armor, power supply for civil large excavation equipment (tank, armored vehicle, military large armored vehicle, civil large excavation equipment, large crane, etc.) |
Specification:
| ITEM | SPECIFICATION |
| Nominal capacity | 2200 mAh@0.5C |
| Minimum capactiy |
2150 mAh@0.5C (Discharge the cell from 4.2V to 2.75V by 0.5C current) |
| Nominal voltage | 3.6V |
| Charging voltage | 4.2 ± 0.05 V |
| Discharg ending voltage | 2.75 ± 0.05 V |
| Standard charge current | 0.5C (1100mA) |
| Standard discharge current | 1C (2200mA) |
| Max charge current |
1C (T ≥ 10℃) 0.5C (10℃>T≥0℃) |
| Max continuous discharge current | 8C (27℃ ≥ T ≥ 23℃) |
| Max pulse discharge current | 10C (27℃ ≥ T ≥ 23℃) |
| Max recommended charge and discharge cell body temperature |
Charge: 0~45℃ Discharge: -20~60℃ |
| Maximum short term allowable charge and discharge cell body temperature. Charging and discharging at these conditions will shorten cell cycle life. |
Charge:60℃ Discharge: 75℃ |
| Internal resistance | ≤22mΩ (AC Impedance, 1000Hz) |
| Cell dimension |
Height: 65.1 mm Diameter: 18.4 mm |
| Weight | ≤ 48g |
Packaging and Shipping:
Certificate:
Warnings:
| Warnings | |||||||
| 1.Do not submerge the battery in the water. | |||||||
| 2.Do not mix fresh batteries with used batteries. | |||||||
| 3.Do not mix batteries with metal stuff together. | |||||||
| 4.Do not insert batteries with the (+) and (-) reversed. | |||||||
| 5.Do not disassemble, dispose in fire, heat or short circuit. | |||||||
| 6.Do not put the battery in a charger or equipment with wrong terminals connected. |
FAQ:
Q1: What is your production capacity?
A: Our production capacity can reach to 200,000 pcs per day.
Q2: What about the lead time?
A: Sample needs 1 day, neutral order of mass production needs 3-7 working days. If OEM of bulk orders, it would be about 7~15 days.
Q3: How do you ship the goods and how long does it take to arrive?
A: DHL, UPS, FedEx or TNT for samples. Shipping time depends on the way you choose. Airline and sea shipping also optional.
Q4: What's the payment term?
A: T/T, L/C, Paypal are acceptable. Mostly 30% T/T in advance, the rest paid before shipping.
Q5: What about the quality of your battery?
A: We only produce safe, reliable and longetive battery, all products have passed the CE, RoHS certifications.
